NV6-22W/R1-IDU

Wall mounted

Počisti

This NØRDIS VRF wall-mounted indoor unit features an elegant ultra-thin design, provides stable airflow with an automatically adjusting fan motor, offers ultra-wide and long-range air distribution, and ensures effective air purification with built-in coarse and PP filters plus an optional silver ion module to remove dust, odors, and bacteria. It is easy to maintain thanks to its removable horizontal baffle, making it ideal for public and commercial spaces, and it comes with a remote controller for convenient operation.

Monterji
Pokličite nas
+370 37 373248
Vprašajte
Stopite v stik z nami

Opis

Main features

Advantages of the model:

Recommended places – workshop, hotel, restaurant, shopping mall, ballroom, bar and other large space places.

Built-in coarse filter, PP filter screen, optional silver ion purification module, effectively remove large particles in the air, absorb formaldehyde and odor, eliminate germs.

The horizontal baffle of the unit is easy to remove for easy cleaning and maintenance.

The panel swing motor system uses a highprecision stepper motor with an intelligent up-and-down control mechanism, enabling ultra-wide-angle and large-range air distribution.

Remote controller

  • Cooling / dehumidification / fan / heating / automatic and other operation settings
  • Temperature / fan speed setting
  • Sleep/timer/swing/turbo and other functions

The appearance of the remote control may differ from that shown in the picture.

Wired controller

  • Cooling / dehumidification / fan / heating / automatic and other operation settings
  • Temperature / fan speed setting
  • Sleep/timer/swing/turbo and other function settings
  • Monitoring function, big LCD screen displays the operation status of the unit
  • Remote control signal available

Central controller

  • 7 inches and colorful screen display, beautiful appearance, touch screen, easy operation.
  • A variety of combinations, single or multiple machines can be operated simultaneously.
  • Up to 16 systems and 1280 indoor units can be connected, easy to set indoor units parameters.
  • It also has the schedule setting and historical fault query function.

Wifi module

Connect the WiFi module with the air-conditioning system, and then match the WiFi module with the wireless router through the mobile phone APP, and the air-conditioning equipment is networked, so that the cell phone APP can realize remote control of the air-conditioning system from a different place and enjoy the convenience interconnection.

Protocol Converter

A Protocol Converter in a VRF system is a device that enables communication between the VRF air conditioning units and the building management system (BMS). It converts the VRF system’s communication protocol into standard formats such as Modbus allowing centralized monitoring, control, and integration of the HVAC system within the overall building automation network.

AHU Connection KIT

Solution to extend NØRDIS VRF technology to third party Air Handling Units.
• Easy for connecting to third party AHU
• Setting capacity by DIP
• Remoter or wire controller can be chosen
• 3 steps fan motor speed, Low/Mid/High
• Error status: No error or error occurred

Certified by Eurovent

This certification guarantees that NØRDIS VRF systems deliver true, tested performance, offering confidence to installers, engineers, and end users alike. It also demonstrates that NØRDIS products fully comply with European energy efficiency and environmental standards, ensuring sustainable comfort solutions for modern buildings.

Documents

Here you can download all the most important documents related to this product and its use.

Technical data
