NV6-45CF/R1-IDU

Ceiling and floor

Anulează

This NØRDIS VRF Ceiling and Floor indoor unit features an ultra-thin design suitable for various interior styles, a wide 0°–110° air supply angle that ensures more even and comfortable room temperature, dual-side condensate drainage from either the left or right, easily detachable plastic blowers for convenient maintenance, and flexible installation options allowing it to be mounted either on the ceiling or standing on the floor. It also comes with a remote controller for easy operation.

Instalatori
Sunați-ne
+370 37 373248
Întrebați
Contactați-ne

Descriere

Main features

Advantages of the model:

Recommended places – Living room, study, reference room, negotiation room and other places

Compact design which fits for various room styles.



The air supply angle is from 0 to 110°, making the indoor temperature more uniform and more comfortable.



Condensing water can be drained both from left and right side.

Universal designed parts and assemblies are used, which makes maintenance easy.

Two ways of installation available, ceiling suspended and floor standing.

Wire control (optional) is available,especially for hotel rooms, offices,etc.

Remote controller

  • Cooling / dehumidification / fan / heating / automatic and other operation settings
  • Temperature / fan speed setting
  • Sleep/timer/swing/turbo and other functions

The appearance of the remote control may differ from that shown in the picture.

Wired controller

  • Cooling / dehumidification / fan / heating / automatic and other operation settings
  • Temperature / fan speed setting
  • Sleep/timer/swing/turbo and other function settings
  • Monitoring function, big LCD screen displays the operation status of the unit
  • Remote control signal available

Central controller

  • 7 inches and colorful screen display, beautiful appearance, touch screen, easy operation.
  • A variety of combinations, single or multiple machines can be operated simultaneously.
  • Up to 16 systems and 1280 indoor units can be connected, easy to set indoor units parameters.
  • It also has the schedule setting and historical fault query function.

Wifi module

Connect the WiFi module with the air-conditioning system, and then match the WiFi module with the wireless router through the mobile phone APP, and the air-conditioning equipment is networked, so that the cell phone APP can realize remote control of the air-conditioning system from a different place and enjoy the convenience interconnection.

Protocol Converter

A Protocol Converter in a VRF system is a device that enables communication between the VRF air conditioning units and the building management system (BMS). It converts the VRF system’s communication protocol into standard formats such as Modbus allowing centralized monitoring, control, and integration of the HVAC system within the overall building automation network.

AHU Connection KIT

Solution to extend NØRDIS VRF technology to third party Air Handling Units.
• Easy for connecting to third party AHU
• Setting capacity by DIP
• Remoter or wire controller can be chosen
• 3 steps fan motor speed, Low/Mid/High
• Error status: No error or error occurred

Certified by Eurovent

This certification guarantees that NØRDIS VRF systems deliver true, tested performance, offering confidence to installers, engineers, and end users alike. It also demonstrates that NØRDIS products fully comply with European energy efficiency and environmental standards, ensuring sustainable comfort solutions for modern buildings.

Documents

Here you can download all the most important documents related to this product and its use.

Technical data
pdf
